Cable HDMI 10M

UTP Cable Cat5e 305m Lanberg Stranded Gray CCA

Product specification:

– LAN cable category 5e UTP (unshielded).
– Length 305m.
– The wires are made of copper conductor cable (CCA).
– AWG 24 (4*2*0.2mm).
– Conductor stranding: stranded.
– Color: grey RAL7035.
– Printed length counter at every meter of cable.
– External PVC insulation: 5.0mm.
– HDPE conductor insulation: 0.93mm.
– Operation up to 100Mhz.
– Package: cardboard box.
– Packaging dimensions (W x D x H): 36x23x36 cm.

Electrical characteristics (20 degrees):

– Conductor resistance (max.): 30 – 45Om / 305m.
– Insulation resistance (min.): 5000mOm km.
– Pair-to-Ground capacitance: < 330PF / 100m.
– Characteristic impedance: < 100Om (+/- 15).
– Transport and storage temperature: 0 – 60 degrees.
– Operating temperature: -20 – 70 degrees.
– Working distance: 80-120m.

Cable intended to be used for short-distance. Fluke’s compliance has not been confirmed.
